Toyota Old RAV4 Android 7 Inch DVD Navigation Integrated Machine

1,High Speed CPU processor,Android 7.1 OS

2,1.6GHz Quad Core,Cortex A9,1.6GHz Frequency

3,600Mhz Mali-400 MP4 GPU,600MHz Frequency

4,Low Leakage,high performance 28nm HKMG technology

5,High speed storage,RAM DDR3 1GB

6,16GB Applied high speed eMMC Flash,ROM 16GB

7,1 024*600 and 800*480 resolution supported

8,Supported Video format:MPEG-1,MPEG-2,MPEG-4,H264,H263,VC1,RV,RMVB,DivX,Sorenson Spark,VP8,AVS Stream etc

9,Two USB2.0 ports,one of them support OTG-USB,two SD card ports

10,capacitance touch screen

11,Supports a variety of audio formats: MP5, MP3, MP2, AAC, OGG, RA, WAV, FLAC, APE, etc.

12,upgrade via SD or USB port

13, Support a variety of Internet access like 3G Internet access, WIFI connection,USB/Android phone connections, while providing WIFI hotspot for other mobile devices Internet access in the vehicle.

14, Many Android application program can be downloaded.

15, support 3D digital navigation map,

16, reversing video function, reversing track, Driving recorder (optional)

17, support Ipod,touch,iphone4,iphone4S and many other devices connection.

18,Picture: support format JPEG, GIF, PNG, BMP file

19,Support Bluetooth,DVD, FM/AM Radio，RDS

20,1080P HD video decode playing via TF Card/USB

21,Compatible with external 1000GB Hard Disk via USB port

22,Can Bus decode box function:

a, supporting multi-function entertainment steering wheel control

b, decoding ACC output

c, decoding reversing control output

d, decoding illumination control output

e, decoding brake detection output

f, supporting original car audio information display (partly support)

Optional Functions:

1) DVB-T / ISDB-T/ ATSC

2) Rear View Camera

3) DVR

4)DAB

5)DVD

Material supplier:

2)CPU：STM32F100VC U.S.A

2)Audio IC:BD3702 FV ROHM Japan

3)Memory IC: W9812G6IH-6 128M Korea

4)Backlight IC:AT24C02 ATMEL U.S.A

5)Decoding IC:MTK1389DE/J Taiwan

6)Amplifier IC:TDA7388 Europe

7)DVD Optical head:
