Product Features:

A set of video input signals is provided for output to 8 sets of output devices. Can be transmitted over long distances, up to 30M. Supports 3-layer stacked serial connection - more 8/64/512 group signal output. Lightweight design for placement on the table or on the wall. Video split rate - up to 1920x1440 @60Hz. Support DDC, DDC2, DDC2B function (only 1 connection port). Supports displays such as XGA, SVGA, VGA, and Multisync. Supported operating systems: Windows 7, Windows 2000, Windows XP, Mac, Sun, LINUX.

Product parameters:

Input interface: 1 channel VGA 15HDF interface input

Output interface: 8-channel VGA15HDF interface synchronous output

RGB analog channel: bandwidth 250MHz

Input level: 0.5-1Vp-p

Output impedance: 75Ω

Line sync channel: input level 0.7-5Vp-p

Transmission distance: 30m

Support resolution: 1920*1440

Power: DC 9V 50/60Hz 5W housing: metal

Product Display
