E-Zhou HDMI Audio Splitter HDMI Splitter 4K*2K 1.4 Version Audio Converter

specification

Brand :: E-Zhou

Model Number :: EZ80265

Source category :: Spot

Types of :: Audio splitter

Resolution :: 4K

Power management :: Support

Fastest shipping time :: 1-3 days

Place of origin :: Guangdong,China

product Description

Product Details:

Product Information
Name: hdmi Audio Splitter
Brand: E-
Zoo Item No.: EZ0265
Color: Black
Product Features
l 1 Convert HDMI input to an HDMI output, a fiber-optic audio output and an R/L analog audio output
l 2 Audio output support: Fiber + R/L Analog audio output
l 3 Input resolution: Up to 3840x2160@30Hz
l 4 Enables audio signal synchronization separation. PASS/2.0CH/5.1CH three audio modes are available
l 5 LED indicator: When converter power When connected, the red LED will light up; when successfully connected to the HD TV, the green LED will light up;

Product Usage
This is a high-performance, versatile HD audio extractor that extracts audio signals from HDMI HD signals to the amplifier system. This results in an audio effect that is difficult to achieve with TV speakers.

Features:
l 1 Convert HDMI input to HDMI output, one fiber audio output and one R/L analog audio output
l 2 Audio output support: Fiber + R/L Analog audio output
l 3 Input resolution: up to 3840x2160@30Hz
l 4 It can realize the synchronous separation of audio signals. PASS/2.0CH/5.1CH three audio modes are available.
l 5 LED indicator: When the converter power is turned on, the red LED will light up; when successfully connected to the HDTV , green led will light up;

product parameters:
HDCP version...................................... ............HDCP 1.4
HDMI version................................. ................ HDMI 1.4b
supports resolution... 2160p@30Hz/1080p@50/60Hz/1080i/720p/1576i/480p/480i
support video color Format....................24bits/deep color 30bit, 36bit
audio output.................. ................................L/R+ fiber
maximum bandwidth............ .........................................340MHz
Maximum transfer rate............................................... 10.2Gbps
Input/Output TMDS Signal........................0.5-1.5Volts pp(TTL)
Input/Output DDC Signal.... .............................5Volts pp (TTL)
input cable distance............ ............<=7m AWG26 standard cable HDMI
output cable distance........................<=8m AWG26 Standard cable HDMI
maximum operating current.......................................... .....500mA
power format........................ Input: AC (50/60Hz) 100V-240V; Output: DC5V/1A
operating temperature range... ...................................(-15 to +55°C)
Working mode range... ................................5 to 90% RH (no condensation)
size (length x width x height). .............................84.5 x 61.8 x 21 (mm)
weight............ ..............................................135g

package contents:
converter................................................ ..........1pcs
5V USB power cable (optional).................................... ............1pcs
5V 1A power adapter (optional) ............................. ..............1pcs
user manual.................................... .......................1pcs
